MBD-X10DRi (16 DIMMs 12" x 13")
Dual socket R3 (LGA 2011) supports,Intel® Xeon® processor E5-2600 v3/v4 ,family; UPI up to 9.6GT/s,Intel® C612 chipset,Up to 2TB† ECC 3DS LRDIMM , up to,DDR4- 2400†MHz; 16 DIMM slots,3 PCI-E 3.0 x16 and 3 PCI-E 3.0 x8,Intel® i350 Dual port GbE LAN
Model :
X10DRi


-
Dual socket R3 (LGA 2011) supports
Intel® Xeon® processor E5-2600 v3/v4
family; UPI up to 9.6GT/s - Intel® C612 chipset
-
Up to 2TB† ECC 3DS LRDIMM , up to
DDR4- 2400†MHz; 16 DIMM slots - 3 PCI-E 3.0 x16 and 3 PCI-E 3.0 x8
- Intel® i350 Dual port GbE LAN
- 10 SATA3 (6Gbps); RAID 0, 1, 5, 10
-
Integrated IPMI 2.0 and KVM with
Dedicated LAN - 5 USB 3.0 (2 rear, 2 via header(s), 1 Type A), 6 USB 2.0 (2 rear, 4 via header(s))
Part List
|
