AIE-PO22/32 | AIE-PN32/42
• Supports NVIDIA Jetson Orin™ NX and Orin Nano™ module
• 1 x M.2 B-Key, 1 x M.2 E-Key, 1 x M.2 M-Key (128GB built-in)
• 2 x RJ-45 GbE ports
• Wide input voltage range from 12 to 24 VDC
• Operating temperature -25°C ~ +55°C
• Fanless Design
• 1 x M.2 B-Key, 1 x M.2 E-Key, 1 x M.2 M-Key (128GB built-in)
• 2 x RJ-45 GbE ports
• Wide input voltage range from 12 to 24 VDC
• Operating temperature -25°C ~ +55°C
• Fanless Design
Model :
AIE-PO22/32 | AIE-PN32/42
| ● Up to 80 x AI performance enables AI inference in the smallest Jetson form factor |
|
The NVIDIA Jetson Orin NX module offers up to 100 TOPS, 3 times more than the NVIDIA Jetson AGX Xavier™ module, and approximately 5 times the NVIDIA Jetson Xavier™ NX module; NVIDIA Jetson Orin Nano offers up to 40 TOPS, 80 times the NVIDIA Jetson Nano™ module. In other words, NVIDIA Jetson Orin NX and Orin Nano module set new standard for mainstream and entry-level edge AI in the smallest Jetson form factor. |
| ● Comprehensive M.2 for internal and external expansion |
| AIE-PO22/32 and AIE-PN32/42 are fanless systems with high expansion ability, built in 1x M.2 B-Key for LTE/5G, 1x M.2 E-Key for Wifi/BT and 1x M.2 M-Key for storage. To avoid insufficient data storage for edge computing, AIE-PO22/32 and AIE-PN32/42 support external M.2 2242 NVMe with fast data transmission. |
| ● Wide input power and fanless design for smart city and smart agriculture |
|
To cater to diverse applications, such as smart city and smart agriculture, where cost-effective maintenance and improved reliability are crucial, AIE-PO22/32 and AIE-PN32/42 have been specifically designed with a fanless and silent mechanism. These systems are capable of operating within a wide temperature range of -25°C to 55°C. Additionally, they support a wide input power range from 12 to 24 VDC, enabling flexible power supply options. |
| Model Number | AIE-PO22 | AIE-PO32 | AIE-PN32 | AIE-PN42 |
| Module Compatibility | NVIDIA Jetson Orin Nano 4GB | NVIDIA Jetson Orin Nano 8GB | NVIDIA Jetson Orin NX 8GB | NVIDIA Jetson Orin NX 16GB |
| AI Performance | 20 TOPS | 40 TOPS | 70 TOPS | 100 TOPS |
| GPU | 512-core NVIDIA Ampere architecture GPU with 16 Tensor Cores | 1024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores | 1024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores | |
| CPU | 6-core Arm® Cortex®-A78AE v 8.2 64-bit 1.5MB L2 + 4MB L3 | 6-core Arm® Cortex®-A78AE v 8.2 64-bit 1.5MB L2 + 4MB L3 | 8-core Arm® Cortex®-A78AE v 8.2 64-bit 2MB L2 + 4MB L3 | |
| Memory | 4GB 64-bit LPDDR5 34 GB/s | 8GB 128-bit LPDDR5 68 GB/s | 8GB 128-bit LPDDR5 102.4 GB/s | 16GB 128-bit LPDDR5 102.4 GB/s |
| Storage | 1 x M.2 M-Key 2242 (NVMe 128GB built-in) | |||
| Display | 1 x HDMI 2.0 Type A | |||
| LAN | 2 x RJ-45 GbE ports | |||
| USB |
2 x USB 3.2 Gen2 Ty pe A (supports up to 10Gbps shared) 1 x OTG Type-C |
|||
| I/O Interfaces |
5 x GPIO, 1 x UART, 1 x I2C, 1 x RS-232, 1 x RS-422/485 (2-in-1), 1 x CAN (isolation; support CAN FD), 1 x microSIM Card Slot |
|||
| Expansion |
1 x M.2 B-Key 3042/3052 (LTE/4G/5G) 1 x M.2 E-Key 2230 (WiFi/BT) |
|||
| MISC. Function | 1 x Power Button, 1 x Recovery Button, 1 x Reset Button | |||
| Power Input/Connector | DC-in 12-24VDC / 4-Pin DC Jack Power Connector | |||
| Power consumption |
Idle: 5.5 W Full Loading: 25.95* W |
Idle: 6.4 W Full Loading: 35.45* W |
||
| *For more test condition information, please refer to user manual | ||||
| Dimension (WxDxH) | 137.6 x 125 x 71.5 mm (5.41 x 4.92 x 2.81 in) | |||
| Mounting | Wall Mount (optional) / Din Rail (optional) | |||
| Net Weight | 1.36 kg (3 lb) | |||
| Vibration | 1 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis | |||
| Shock | 10 G, IEC 60068-2-27, half sine, 11 ms duration | |||
| Temperature |
Operating: -25°C ~ +55°C (-13°F ~ +131°F) with 0.5 m/s air f low Storage: -40°C ~ +85°C (-40°F ~ +185°F) |
|||
| Humidity | 95% @ 40°C (104°F) (non-condensing) | |||
| Software Support | Linux (Support Jetpack 5.0 above) | |||
| Certification | CE / FCC Class A / UKCA | |||
