ASA 6W Low/High I/P wide range Isolated DC-DC Converters

The ASA series of low/high-input 6 watt isolated DC-DC converters features an ultra wide 4:1 input voltage range of 9–36 Vdc and is designed primarily for use with nominal 12 V or 24 V supplies.

Model : asa 6w low/high i/p wide range series

Q'ty :

There is a choice of four single output models, offering voltages of 3.3 V, 5 V, 12 V or 15 V, and three dual output models offering +5/-5 V, +12/-12 V or +15/-15 V. The converters are fully encapsulated in a compact 1.25 x 0.8 inch (31.7 x 20.3 mm) metal case and have a height of just 0.4 inch (10.2 mm). They are ideal for ruggedized applications involving harsh environments.

Standard features include 1,500 Vdc input/output isolation and short-circuit protection with auto-restart. Typical efficiency is 81%. ASA series 6 watt converters have an operating temperature range of -40 to 71˚C without derating and are suitable for diverse low power applications in areas such as industrial automation, instrumentation, test and measurement, and telecommunications. All models with an output voltage of 5V or higher have a 6 watt power rating.

Total Max Power:
6 W
Total Max Current:
1.2 A
Input Voltage:
9 V to 75 V
Output Voltage:
-15 V to 15 V
Outputs:
Single, Dual
Size (L x W x H):
1.250" x 0.800" x 0.400"
Warranty:
2 years
Operating Temperature:
-40°C to +71°C
