The UltraVolt C series includes seven models ranging from 125 to 6,000 VDC of maximum high voltage power. They C series models are available in single-output positive or negative polarities. From a 24 VDC input, access up to 30 W of fast-rise charging power with less than 1% overshoot. Choose from PCB or chassis mounts and select mechanical and electrical performance options to meet your specific application needs.

Advanced Energy's UltraVolt C series is ideal for high-energy pulsers, amplifiers, and discharge devices with large capacitance, fast repetition rates, or high-current loads.

• Achieve higher system throughput with quick capacitor charging
• Minimize stress on storage capacitors, enhance system reliability and simplify product design
• Upgrade module and system performance without changing PCB or chassis layout
• Responsive and adaptable control of high voltage capacitor charging processes
• Expand mechanical integration, external RF protection, and interconnection possibilities
• Fast-rise charging power delivered from an optimized design
• Limited overshoot, typically less than 1% of high voltage setpoint, depending on the application
• Configurable high-voltage out, power and polarity in a common, compact footprint
• Full-range control and monitoring of high-voltage output and current
• Selection of electrical, shielding and mechanical integration options
