CSU2000ADC
Advanced Energy's Artesyn CSU2000ADC is housed in the industry standard 1U x 73.5 x 185 mm form factor featuring -48Vdc input voltage. This DC/DC power supply belongs to the CRPS family of products, and matches the mechanical
form and fit of Advanced Energy's AC/DC power supplies. The common form, fit, and function for all products in the family provides a path for power capacity flexibility, futureproofing your system designs.
form and fit of Advanced Energy's AC/DC power supplies. The common form, fit, and function for all products in the family provides a path for power capacity flexibility, futureproofing your system designs.
Model :
CSU2000ADC CRPS Power
- 2000 W output power
- High power and short form factor
- 1U power supply
- High density design: 62 W/in3
- Uses two-hole terminal lugs to handle high input current
- Inrush current control
- N+M redundant N+M ≤ 4
- Hot-pluggable
- Active current sharing
- Full digital control
- PMBus® compliant
- Accurate input power reporting
- Compatible with Artesyn’s Universal PMBus GUI
- Reverse airflow option
