ATX Motherboard-Intel® Core™ i7/i5/i3/Pentium® processor

LGA1155 3rd Intel® Core™ i7/i5/i3/
Pentium® ATX with DVI/VGA, Dual GbE LAN
Model : AIMB-701G2-00A1
  • Supports Intel®Core™ i7/i5/i3/Pentium processor with H61 chipset
  • Two DIMM sockets support up to 16 GB DDR3 1066/1333
  • Supports dual display VGA/DVI-D and dual GbE LAN
  • Supports RS232/422/485 with auto flow control
  • Supports One PCIe x16 and 5 PCI expansion slots
