AEE 50W High I/P DC-DC Converters
The AEE 50W series is a high efficiency, highly compact and high density DC-DC converter designed to be used in applications where a very wide input voltage range is required.
Model :
aee 50w high i-p version series
The family covers an input voltage of 18Vdc to 75Vdc. The fully potted, metal cased construction also makes this family an ideal choice for harsh environments.
There are 5 single output voltage variants available.
There are 5 single output voltage variants available.
-
Total Max Power:
50 W -
Total Max Current:
10 A -
Input Voltage:
18 V to 75 V -
Output Voltage:
3 V to 28.8 V -
Outputs:
Single -
Size (L x W x H):
2.000" x 1.000" x 0.400" -
Warranty:
2 years -
Operating Temperature:
-40°C to +85°C
